1.3 Inch TFT IPS LCD display, 240×240 pixels, MCU/SPI/RGB Interface

Product highlights

This 1.3 inch TFT display is a mini TFT display only 1.3” diagonal, but boasting an impressive high resolution of 240×240 pixels, with a pixel density of 260 PPI.

Thanks to IPS panel, this HD (High Density) 1.3” TFT LCD provides a full-angle viewing experience, which ensures the images still look great up to 80 degrees off axis in any direction.

With its 3ms response time and 800:1 contrast ratio, it produces the visuals of high quality.

The design of 6 o′clock viewing direction makes it ideal for wearable and portable devices.

Product description

This 1.3” TFT display is a full color mini-display with IPS panel / 3ms Response Time / Active-Matrix TFT / Medium Brightness / Optional Touchscreen / Resolution of 240×240 / Contrast ratio of 800:1 / ROHS Compliant.

The high quality, low price product is always our long-term goal.

Technical Details

Download Product References Below

Product Datasheet: GFC240240-1.3INTM

Controller Datasheet: ST7789V

More for 1.3 Inch TFT Display

This high resolution 1.3” TFT LCD is at such a surprisingly low price, giving you an advantage against competitors who use OLED displays. It is an ideal choice to equip products at an unbeatable price.

Importantly, this active-matrix LCD has a longer life time than that of a passive-matrix OLED.

A SPI interface works easily with any microcomputers or microcontrollers, so it is suitable for applications requiring a small, full color and bright (400 nits) display, such as wearable electronics, IOT devices, handheld instruments and home appliances. Furthermore, MIPI, MCU or RBG interface version is optional in our custom service for your requirement.

IPS LCD technology offers a wide viewing angle and a good contrast ratio of 800:1. This makes the color look great at any condition. Furthermore, 6 o′clock viewing direction design ensures excellent performance in portable devices.

Its driver (ST7789) is widely used in many mini Arduino TFT displays, with which engineers design their projects. Then, manufacturers can easily put it into their end products.

The operating temperature ranging from -20°C to +70°C along with a storage temperature from -30°C to +80°C makes it work well in any condition.

Don’t miss out on our incredible selection!

This is just one of our famous TFT LCD modules; In Go2Display, you can find more.

If none of these part numbers meet your requirements in any term, contact us(sales@go2display.com), who are willing to work with you.
