1.4'' OLED 400x400 Circular Screen Wholesale

1.4'' OLED 400x400 Circular Screen

Model / SKU: GFO400400-1.4ANT

1.4'' OLED 400x400 Circular Screen is an AMOLED with full color reproduction, high contrast, wide viewing angles, and optional capacitive touchscreen.

Diagonal Dimension (Inches)

1.4

LCD Active Area WxHxD (mm)

38.83 x 38.21

Display Mode

AMOLED

Interface Type

MIPI Interface, 24 pins Connector

Model / Series Name	GFO400400-1.4ANT
Diagonal Dimension (Inches)	1.4
Dots WxH	400×400
Module Size WxHxD (mm)	38.83 x 38.21
LCD Active Area WxHxD (mm)	38.83 x 38.21
Display Mode	AMOLED
Viewing Angle	Left: 80 / Right: 80 / Top: 80 / Bottom: 80 degrees;
Contrast Ratio	100000:1
Brightness	350 cd/m2
Display Colors	16.7 M, 100% NTSC
IC	RM69330
Interface Type	MIPI Interface, 24 pins Connector
Touch Panel	Optional
Logic Power Supply	2.8V
Operating Temperature	-20 ~ 60 °C
Storage Temperature	-30 ~ 70 °C

Model / Series Name

GFO400400-1.4ANT

Diagonal Dimension (Inches)

1.4

Dots WxH

400×400

Module Size WxHxD (mm)

38.83 x 38.21

LCD Active Area WxHxD (mm)

38.83 x 38.21

Display Mode

AMOLED

Viewing Angle

Left: 80 / Right: 80 / Top: 80 / Bottom: 80 degrees;

Contrast Ratio

100000:1

Brightness

350 cd/m2

Display Colors

16.7 M, 100% NTSC

RM69330

Interface Type

MIPI Interface, 24 pins Connector

Touch Panel

Optional

Logic Power Supply

2.8V

Operating Temperature

-20 ~ 60 °C

Storage Temperature

-30 ~ 70 °C

Product highlights

Wholesale Price: As an OLED manufacturer, Go2Display can offer this circular AMOLED at factory price.

Popular: The market has shown that this size of a smartwatch is very popular, like Ticwatch S Smartwatch-Knight. You can use it safely on a watch or other wearable products.

Custom OLED Solution: We offer custom OLED display solutions based on your size, shape, interface, IC, FPC cable shape, etc.

Product description

This 1.4” OLED screen is a circular module with AMOLED panel / Resolution of 400×400 / Optional Touchscreen / MIPI Interface / RM69330 built-in IC / FPC connector.

The high quality, low price product is always our long-term goal.

Technical Details

Download Product References Below

Product Datasheet: GFO400400-1.4ANT

Driver Datasheet: RM69330

1.4'' OLED 400x400 Circular Screen image quality

1.4'' OLED 400x400 Circular Screen contrast ratio

More Details about this 1.4” Circular Screen

This 1.4-inch OLED display has a circular shape with a 400x400 resolution.

This AMOLED screen emits light from its own organic materials. This is why it has a high contrast ratio of 100,000:1, and a 160 degrees wide viewing angle.

It can also show all 16.7 million colours in the NTSC colour gamut. With 350 cd/m2 brightness, users can see bright and sharp images.

It has a MIPI interface and a built-in RM69330 driver IC. So, it is easy to use it as a display replacement for your existing products. It can also be easier to use if you add a capacitive touch panel.

Even when the temperature is under 0°C or above 40°C, it can still work well.

Custom OLED Solution

With all of the above benefits, this 1.4-inch circular AMOLED screen is perfect for smartwatches and other wearable devices that have limited space but need to show details.

Go2Display is ready to provide custom OLED display solutions to meet your specific requirements.
