4.21 Inch Round LCD Display Wholesale

4.21 Inch Round LCD Display

Model / SKU: GFC700700-4.21INTM

4.21 Inch Round LCD Display is an IPS TFT module with circular shape, high contrast (800:1), wide viewing angles, high resolution (700×700), touchscreen.

Diagonal Dimension (Inches)

4.21 (4.2)

LCD Active Area WxHxD (mm)

105.84 x 105.84

Display Mode

IPS, Transmissive, Normal white

Interface Type

24-bit parallel RGB Interface

Model / Series Name	GFC700700-4.21INTM
Diagonal Dimension (Inches)	4.21 (4.2)
Dots WxH	700 x 700
Module Size WxHxD (mm)	132.50 x 132.50 x 9.30
LCD Active Area WxHxD (mm)	105.84 x 105.84
Display Mode	IPS, Transmissive, Normal white
Viewing Angle	All
Contrast Ratio	800:1
IC	ST1633I from Sitronix
Interface Type	24-bit parallel RGB Interface
Logic Power Supply Voltage	2.8V to 3.6V
Backlight	White LEDs
Luminance	1000 cd/m2
Touch Panel	None or Optional CTP (Capacitive Touch Panel)
Operating Temperature	-20 ~ 70 °C
Storage Temperature	-30 ~ 85 °C

Model / Series Name

GFC700700-4.21INTM

Diagonal Dimension (Inches)

4.21 (4.2)

Dots WxH

700 x 700

Module Size WxHxD (mm)

132.50 x 132.50 x 9.30

LCD Active Area WxHxD (mm)

105.84 x 105.84

Display Mode

IPS, Transmissive, Normal white

Viewing Angle

All

Contrast Ratio

800:1

ST1633I from Sitronix

Interface Type

24-bit parallel RGB Interface

Logic Power Supply Voltage

2.8V to 3.6V

Backlight

White LEDs

Luminance

1000 cd/m2

Touch Panel

None or Optional CTP (Capacitive Touch Panel)

Operating Temperature

-20 ~ 70 °C

Storage Temperature

-30 ~ 85 °C

Product highlights

Round: This shape is good for home security systems, smart mirrors, smart buttons, and other special uses.

Sunlight Readable: Thanks to its brightness of 1000 nits, users can still see the clear screen outdoors. Of course, you can make a custom solution for brightness for other uses.

High Color Performance: It has a high resolution, wide viewing angles, and IPS panel technology. Your product can provide an excellent user experience.

Wholesale Price: As a TFT LCD manufacturer, Go2Display can offer you a factory price.

Product description

This 4.21 inch Round LCD display is a TFT display Module with IPS panel / 700×700 Resolution / Contrast ratio of 800:1 / Optional Touchscreen / RGB Interface / ST1633I Controller / COG Package.

The high quality, low price product is always our long-term goal.

Technical Details

Download Product References Below

Product Datasheet: GFC700700-4.21INTM

Driver Datasheet: ST1633I

Details of this 4.21 Inch Round LCD Display

This round LCD display has a 4.21-inch screen with a 700x700 resolution.

As an IPS LCD, it features wide viewing angles and a good contrast ratio of 800:1. Plus, it is a sunlight-readable display with 1000 cd/m2 brightness.

White LEDs as the backlight source give it such a bright light.

The display uses a ST1633I driver IC supporting a parallel RGB interface. So, engineers can easily connect it to a range of host processors and systems.

An extended operating temperature makes it work well in different conditions.

Its
